LiteLLM Trace Analysis with Parseable

Introduction

LiteLLM is an open-source LLM gateway that provides a unified API for 100+ LLM providers. It acts as a proxy between your application and LLM APIs like OpenAI, Anthropic, Azure, Bedrock, and self-hosted models, giving you a single endpoint with built-in load balancing, fallbacks, and spend tracking.

But with great abstraction comes a new challenge: visibility. When your application makes dozens of LLM calls across different providers, you need answers to questions like:

• Which model is slowest? Which is most expensive?
• What's the token usage breakdown per user or feature?
• Where are the bottlenecks in my LLM-powered workflows?

LiteLLM has built-in OpenTelemetry support, which means you can send traces to any OTLP-compatible backend. In this guide, we'll set up a pipeline to send LiteLLM traces to Parseable through the OpenTelemetry Collector, giving you SQL-queryable LLM observability.

Why Parseable for LLM Traces?

Traditional APM tools weren't built for LLM workloads. They'll show you spans and latencies, but they won't help you answer:

• What was the total token cost across all Claude calls yesterday?
• Which prompts are generating the longest responses?
• How does latency correlate with input token count?

Parseable stores traces as structured data in columnar Parquet format. This means you can:

• Query with SQL
• Correlate across signals
• Control costs
• Set up alerts

Architecture Overview

The pipeline:

LiteLLM → OpenTelemetry Collector → Parseable

1. LiteLLM — Your application uses LiteLLM to call LLM APIs. LiteLLM's OTEL callback exports traces.
2. OpenTelemetry Collector — Receives OTLP traces from LiteLLM and forwards them to Parseable.
3. Parseable — Ingests traces at /v1/traces, stores them in object storage, and exposes them via SQL.

Prerequisites

• Python 3.8+ with LiteLLM installed
• OpenTelemetry Collector installed (installation guide)
• Parseable running and accessible (installation guide)

Step 1: Install LiteLLM with OpenTelemetry

Install LiteLLM and the OpenTelemetry SDK:

pip install litellm opentelemetry-api opentelemetry-sdk opentelemetry-exporter-otlp

Step 2: Configure OpenTelemetry Collector

Create a configuration file otel-collector-config.yaml:

receivers:
  otlp:
    protocols:
      grpc:
        endpoint: 0.0.0.0:4317
      http:
        endpoint: 0.0.0.0:4318

processors:
  batch:
    timeout: 5s
    send_batch_size: 100

exporters:
  otlphttp:
    endpoint: http://localhost:8000
    headers:
      Authorization: Basic YWRtaW46YWRtaW4=
      X-P-Stream: litellm-traces
      X-P-Log-Source: otel-traces
    tls:
      insecure: true

service:
  pipelines:
    traces:
      receivers: [otlp]
      processors: [batch]
      exporters: [otlphttp]

Configuration breakdown:

Start the collector:

./otelcol --config ./otel-collector-config.yaml

Step 3: Configure LiteLLM to Export Traces

Set environment variables to point LiteLLM at the OpenTelemetry Collector:

export OTEL_EXPORTER_OTLP_ENDPOINT="http://localhost:4318"
export OTEL_EXPORTER_OTLP_PROTOCOL="http/json"

Now enable the OTEL callback in your Python code:

import litellm
from litellm import completion

# Enable OpenTelemetry tracing
litellm.callbacks = ["otel"]

# Make an LLM call
response = completion(
    model="gpt-4",
    messages=[{"role": "user", "content": "What is observability?"}]
)

print(response.choices[0].message.content)

Every LLM call will now emit a trace to the OpenTelemetry Collector, which forwards it to Parseable.

Step 4: Using LiteLLM Proxy (Optional)

If you're running LiteLLM as a proxy server, configure it in litellm_config.yaml:

model_list:
  - model_name: gpt-4
    litellm_params:
      model: openai/gpt-4
      api_key: sk-...

litellm_settings:
  callbacks: ["otel"]

environment_variables:
  OTEL_EXPORTER_OTLP_ENDPOINT: "http://localhost:4318"
  OTEL_EXPORTER_OTLP_PROTOCOL: "http/json"

Start the proxy:

litellm --config litellm_config.yaml

All requests through the proxy will now be traced.

Step 5: Query Traces in Parseable

Once traces are flowing, open Parseable UI and select the litellm-traces stream.

Trace Schema

LiteLLM traces include rich metadata:

Example Queries

Average latency by model:

SELECT
  "span_model" AS model,
  AVG("span_duration_ms") AS avg_latency_ms,
  COUNT(*) AS call_count
FROM "litellm-traces"
WHERE "span_name" LIKE '%completion%'
GROUP BY model
ORDER BY avg_latency_ms DESC;

Token usage over time:

SELECT
  DATE_TRUNC('hour', p_timestamp) AS hour,
  SUM("span_input_tokens") AS input_tokens,
  SUM("span_output_tokens") AS output_tokens,
  SUM("span_total_tokens") AS total_tokens
FROM "litellm-traces"
GROUP BY hour
ORDER BY hour;

Slowest requests:

SELECT
  trace_id,
  "span_model",
  "span_duration_ms",
  "span_total_tokens",
  p_timestamp
FROM "litellm-traces"
ORDER BY "span_duration_ms" DESC
LIMIT 20;

Error rate by model:

SELECT
  "span_model" AS model,
  COUNT(*) AS total_calls,
  SUM(CASE WHEN "span_status_code" >= 400 THEN 1 ELSE 0 END) AS errors,
  ROUND(100.0 * SUM(CASE WHEN "span_status_code" >= 400 THEN 1 ELSE 0 END) / COUNT(*), 2) AS error_rate
FROM "litellm-traces"
GROUP BY model
ORDER BY error_rate DESC;

Step 6: Set Up Alerts

Parseable's form-based alerting lets you create alerts without writing queries.

High Latency Alert

1. Navigate to Alerts → Create Alert
2. Configure:
   • Dataset: litellm-traces
   • Monitor Field: span_duration_ms
   • Aggregation: AVG
   • Alert Type: Threshold
   • Condition: Greater than 5000 (5 seconds)
   • Evaluation Window: 5 minutes
3. Add a webhook destination (Slack, PagerDuty, etc.)

Token Spike Anomaly Detection

1. Create a new alert
2. Configure:
   • Dataset: litellm-traces
   • Monitor Field: span_total_tokens
   • Aggregation: SUM
   • Alert Type: Anomaly Detection
   • Sensitivity: Medium
   • Historical Window: 7 days

This will alert you when token usage deviates significantly from historical patterns.

Privacy: Redacting Prompts and Responses

LiteLLM can redact sensitive content from traces:

Redact all messages globally:

litellm.turn_off_message_logging = True

Redact per-request:

response = completion(
    model="gpt-4",
    messages=[{"role": "user", "content": "Sensitive prompt"}],
    metadata={
        "mask_input": True,
        "mask_output": True
    }
)

This keeps request metadata (model, tokens, latency) while hiding the actual content.

Cost Tracking

With token counts in your traces, you can calculate costs:

SELECT
  "span_model" AS model,
  SUM("span_input_tokens") AS input_tokens,
  SUM("span_output_tokens") AS output_tokens,
  -- GPT-4 pricing as example: $0.03/1K input, $0.06/1K output
  ROUND(SUM("span_input_tokens") * 0.00003 + SUM("span_output_tokens") * 0.00006, 2) AS estimated_cost_usd
FROM "litellm-traces"
WHERE "span_model" = 'gpt-4'
  AND p_timestamp >= NOW() - INTERVAL '24 hours'
GROUP BY model;

Adjust the pricing multipliers for your specific models.

Conclusion

With LiteLLM, OpenTelemetry Collector, and Parseable, you get:

• Unified LLM observability — All your LLM calls in one place, regardless of provider
• SQL-powered analysis — Query traces like a database, not a black box
• Cost-effective storage — Object storage pricing instead of per-GB observability fees
• Actionable alerts — Threshold, anomaly, and forecast-based alerting

The setup takes 15 minutes. The visibility lasts forever.
