n8n

Set up end-to-end observability for n8n workflow automation with Parseable using OpenTelemetry.

Overview

Integrate n8n with Parseable to:

Workflow Tracing - Track every workflow and node execution
Performance Metrics - Monitor durations, error rates, and token usage
Structured Logging - Capture logs with Winston + OpenTelemetry
AI Agent Debugging - Debug non-deterministic agentic workflows
Unified Observability - Single OTLP pipeline for logs, traces, and metrics

Architecture

┌───────────┐    ┌───────────────────────┐    ┌──────────────────────┐
│   n8n     │───▶│ OpenTelemetry (OTLP)  │───▶│ Parseable (Datasets) │
│           │    │ - Traces              │    │ - otel-traces        │
│ Workflows │    │ - Metrics             │    │ - otel-metrics       │
│ Nodes     │    │ - Logs (Winston)      │    │ - otel-logs          │
└───────────┘    └───────────────────────┘    └──────────────────────┘

Prerequisites

Docker and Docker Compose
n8n instance
Parseable instance

Quick Start

Clone the observability repository and start the stack:

git clone https://github.com/parseablehq/n8n-observability.git
cd n8n-observability
cp .env.example .env
# Edit .env with your passwords
docker-compose up -d

Access the applications:

n8n: http://localhost:5678 (admin/admin)
Parseable: http://localhost:8000 (admin/admin)

Docker Compose Setup

Environment Variables

Create a .env file:

# Parseable credentials
PARSEABLE_USERNAME=admin
PARSEABLE_PASSWORD=admin

# n8n authentication
N8N_BASIC_AUTH_PASSWORD=admin

# Database password
POSTGRES_PASSWORD=admin

# Optional: Custom domain/protocol
N8N_HOST=localhost
N8N_PROTOCOL=http
WEBHOOK_URL=http://localhost:5678/

Docker Compose Configuration

version: '3.8'
services:
  parseable:
    image: parseable/parseable:latest
    ports:
      - "8000:8000"
    environment:
      - P_USERNAME=${PARSEABLE_USERNAME}
      - P_PASSWORD=${PARSEABLE_PASSWORD}

  n8n:
    build:
      dockerfile: Dockerfile.working
    environment:
      - PARSEABLE_URL=http://parseable:8000
      - OTEL_SERVICE_NAME=n8n-comprehensive
      - N8N_WINSTON_LOGGING=true
    ports:
      - "5678:5678"
    depends_on:
      - parseable
      - postgres

  postgres:
    image: postgres:15-alpine
    environment:
      - POSTGRES_DB=n8n
      - POSTGRES_USER=n8n
      - POSTGRES_PASSWORD=${POSTGRES_PASSWORD}

Verification

Check that telemetry is flowing:

# Check service status
docker-compose ps

# View n8n logs for OpenTelemetry initialization
docker logs n8n-comprehensive | grep "OpenTelemetry"

# Verify Parseable streams exist
curl -s http://localhost:8000/api/v1/logstream \
  -H "Authorization: Basic $(echo -n 'admin:admin' | base64)"

You should see two streams: otel-traces and otel-metrics.

Querying n8n Data

Workflow Execution Metrics

SELECT
  metric_name,
  workflow_name,
  workflow_id,
  data_point_value,
  time_unix_nano
FROM "otel-metrics"
WHERE metric_name LIKE '%workflow%'
ORDER BY time_unix_nano DESC
LIMIT 20

Node Performance Metrics

SELECT
  metric_name,
  node_type,
  node_name,
  workflow_name,
  data_point_value,
  time_unix_nano
FROM "otel-metrics"
WHERE metric_name LIKE '%node%'
  AND node_type IS NOT NULL
ORDER BY time_unix_nano DESC
LIMIT 15

HTTP Request Success Rate

SELECT
  "http.response.status_code",
  COUNT(*) as request_count,
  COUNT(*) * 100.0 / SUM(COUNT(*)) OVER() as percentage
FROM "otel-metrics"
WHERE metric_name LIKE '%http%'
  AND "http.response.status_code" IS NOT NULL
  AND p_timestamp > NOW() - INTERVAL '24 hours'
GROUP BY "http.response.status_code"
ORDER BY request_count DESC

Slowest HTTP Requests

SELECT
  span_name,
  "http.method",
  "http.route",
  EXTRACT(EPOCH FROM (span_end_time_unix_nano - span_start_time_unix_nano)) * 1000 as duration_ms,
  "http.response.status_code",
  span_status_description
FROM "otel-traces"
WHERE span_name LIKE 'GET %' OR span_name LIKE 'POST %'
ORDER BY duration_ms DESC
LIMIT 10

Setting Up Alerts

HTTP Error Rate Alert

Monitor when n8n experiences high error rates:

Dataset: otel-metrics
Monitor: http.status_code by COUNT
Filter: http.response.status_code >= 400
Threshold: Trigger when error count > 900 in 5 minutes
Evaluation: Every 5 minutes

High Response Time Alert

Get notified when API response times exceed thresholds:

Dataset: otel-metrics
Monitor: data_point_value (for duration metrics)
Filter: metric_name LIKE '%http%duration%'
Threshold: Trigger when average response time > 2000ms
Group by: http.route to identify specific endpoints

Alert Delivery Options

Parseable supports multiple notification channels:

Webhook - Send alerts to Slack, Discord, or custom endpoints
Email - Direct email notifications
PagerDuty - Integration for critical production alerts

Best Practices

Layered Alerting - Set up multiple severity levels (warning, critical)
Context-Rich Notifications - Include workflow IDs and execution details
Alert Fatigue Prevention - Use appropriate thresholds to avoid noise
Escalation Policies - Define clear escalation paths
Regular Review - Periodically adjust alert thresholds based on patterns

What You Get

Structured, correlated logs from n8n using Winston + OpenTelemetry
Distributed traces for every workflow and node to pinpoint slow or failing steps
Metrics for durations, error rates, and token usage
Single OTLP pipeline into Parseable for unified storage and analysis
Ready-to-use SQL queries, dashboards, and alerts

Resources

Next Steps

Set up alerts for workflow failures
Create dashboards for n8n monitoring
Configure OpenTelemetry for other services
